Socapex 19 pin Syntax SSX energy cables

Energy cables

for SSX connectors and
power distribution

Energy cables

for SSX connectors and
power distribution

Flexible and easy to handle. Socapex 19 pin compatible professional cables for industrial applications, field equipment, emergency lighting for public areas, audio and video technology. The best choice when winding operations are intensive.

  • Cables for SSX 19pin

    Cables for SSX 19pin
  • Multicore Power Cable

    Multicore Power Cable

    Multicore Power Cable

    for SSX 19pin

    for SSX 19pin

    These Syntax® Multicore Power cables are manufactured with a flexible and impact absorbing external jacket, compliant with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 fire resistant regulations. Thanks to the particular distribution of the inner conductors, the Syntax® Multicore Power cables are anti-knotting and have excellent flexibility, handling, mechanical resistance and easy winding characteristics. They are also suitable for continuous rolling/unrolling either in indoor or outdoor use. Designed for lighting applications, it perfectly matches with our 19 pin SSX power connector series.

  • Technical data

    Technical data

    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 450/750 V
    Temperature range: - 30°C + 70°C


    Part N.CoresInner conductorsDiameter
    7ZF1925E19 G 2.5 mm218 numbered jackets + Green/yellowØ 19,5 mm
  • Multicore Power Cable

    Multicore Power Cable

    Multicore Power Cable

    for SSX 19pin

    for SSX 19pin

    These Syntax® Multicore Power cables are manufactured with a flexible and impact absorbing external jacket, compliant with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 fire resistant regulations. Thanks to the particular distribution of the inner conductors, the Syntax® Multicore Power cables are anti-knotting and have excellent flexibility, handling, mechanical resistance and easy winding characteristics. They are also suitable for continuous rolling/unrolling either in indoor or outdoor use. Designed for lighting applications, it perfectly matches with our 19 pin SSX power connector series.

  • Technical data

    Technical data

    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 450/750 V
    Temperature range: - 30°C + 70°C


    Part N.CoresInner conductorsDiameter
    7ZF1915E19 G 1.5 mm218 numbered jackets + Green/yellowØ 18 mm
  • Multicore Power Cable

    Multicore Power Cable

    Multicore Power Cable

    for SSX 19pin

    for SSX 19pin

    This 18-wire Power Multicore cable is a more compact version of the 7ZF1925E 19-wire model, intended for usage on those applications where the 19th yellow/green wire is not used. The advantages are a slimmer cable for easier handling, excellent flexibility and less total weight. The particular distribution of the inner cables and the material used for the external jacket allow a long cable lifespan even in case of  frequent winding and unwinding cycles typical of mobile usage. The PVC black jacket comply with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 fire resistant regulations, diameter 19,5mm.

  • Technical data

    Technical data

    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 300/500 V
    Temperature range: - 30°C + 70°C


    Part N.CoresInner conductorsDiameter
    7ZF1825E18 G 2.5 mm218 numbered jacketsØ 19,5 mm
  • Multicore Power Cable

    Multicore Power Cable

    Multicore Power Cable

    for SSX 19pin

    for SSX 19pin

    This 18-wire Power Multicore cable is a more compact version of the 7ZF1815E 18-wire model, intended for usage on those applications where the 19th yellow/green wire is not used. The advantages are a slimmer cable for easier handling, excellent flexibility and less total weight. The particular distribution of the inner cables and the material used for the external jacket allow a long cable lifespan even in case of  frequent winding and unwinding cycles typical of mobile usage. The PVC black jacket comply with CEI 20-22/III - IEC 60332-3-24 - EN 50266-2-4 fire resistant regulations, diameter 18mm.

  • Technical data

    Technical data

    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 450/750 V
    Temperature range: - 30°C + 70°C

    Part N.CoresInner conductorsDiameter
    7ZF1815E18 G 1.5 mm218 numbered jacketsØ 18 mm
  • Multicore Power Cable

    Multicore Power Cable

    Multicore Power Cable

    for SSX 19pin

    for SSX 19pin

    This version of 19x2,5 Power Multicore is intended for usage when halogen-free cable is requested. The particular distribution of the inner cables and polyurethane jacket (PUR), provides high shear strength and extremely long lifespan, despite the smaller thickness of the cable sheath. The several advantages are: slim cable for easier handling, less total weight and compliance with halogen-free norms, thanks to the PUR native features. External overall diameter 18 mm, weight 0,62 kg/mt, good flexibility.

  • Technical data

    Technical data

    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 300/500 V
    Temperature range: - 40°C + 80°C


    Part N.CoresInner conductorsDiameter
    7ZF1925PUR19 G 2.5 mm218 numbered jackets + Green/yellowØ 18,5 mm

  • Cables for SSX 19pin with 6 - way grommet

    Cables for SSX 19pin
    with 6 - way grommet
  • Mains Power Cable

    Mains Power Cable

    Mains Power Cable

    for SSX 19pin with 6 - way grommet

    for SSX 19pin with 6 - way grommet

    The strand construction of the Syntax® Mainflex cable has been designed to get the best flexibility with a wide range of external temperatures. This cable has good impact absorbing properties and the external jacket is compliant with CEE 20-22/III - IEC 60332-3-24 - EN 50266-2-4 regulations. In the 7ZF0325 cable the 11.3 mm overall diameter is intended to grant IP67 protection when the cable is used with the six-way rubber grommet of our Syntax® SSX 19 pin Spider connector, for break-in and break-out leads. Possible applications of this cable  are in lighting technology and other current-carrying circuits.

  • Technical data

    Technical data

    Jacket: Black matt PVC flame retardant
    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 450/750 V
    Temperature range: - 30°C + 70°C

    Part N.CoresInner conductorsDiameter
    7ZF03253 G 2.5 mm2Brown - Blue - Green/YellowØ 11,3 mm

  • Cables for SSX 16pin with 4 - way grommet

    Cables for SSX 16pin
    with 4 - way grommet
  • Mains Power Cable

    Mains Power Cable

    Mains Power Cable

    for SSX 16pin with 4 - way grommet

    for SSX 16pin with 4 - way grommet

    The 7ZF0425M cable is the right solution for managing three-phase motors. The three phases are identified by the number placed on the sheath of the inner conductors while the yellow-green wire is used for grounding. The conductors have a cross section of 2.5 mm² that allows you to manage high power.The outer jacket is flexible black PVC, flame retardant comply with IEC 60332-3-24 - EN 50266-2-4

  • Technical data

    Technical data

    Conductors: Black PVC numbered
    Jacket:     Black matt PVC Ø 12.2 mm
    Resistance of conductors: IEC 60344
    Insulation resistance: > 200 MΩ/km
    Operating Voltage: 450/750 V
    Temperature range: - 30°C + 70°C

    Part N.CoresInner conductorsDiameter
    7ZF0425M4 G 2.5 mm2Black - Green/YellowØ  12,2 mm
  • Speaker Power Line Cable

    Speaker Power Line Cable

    Speaker Power Line Cable

    for SSX 16pin with 4 - way grommet

    for SSX 16pin with 4 - way grommet

    This range of Syntax® cables has been developed to obtain maximum flexibility and excellent mechanical properties. The main characteristic is the extremely dense stranding of the conductors’ section, which results in increased conductivity. They feature large conductor size to minimize resistance to high power conduction. All the conductors are numbered and maintained properly clustered inside the outer PVC sheath thanks to the internal lined ridges, even under heavy usage and continuous rewinding. The cores are talc dusted to slide against one another, thus granting optimal handling. The external diameter is perfectly suitable for usage with the most commonly used power connectors. Finally, the arctic polymer PVC jacket allows good flexibility and handling in a wide range of temperatures.

  • Technical data

    Technical data

    Conductors OFC strand: section 2.5 mm² = 147 x 0.15 - 13 AWG
    Operating temperature: - 30° + 70° c.
    D.C.R. 20° C.: sect. 2.5 mm² = 8 Ω/km
    Operating voltage: <50 VC
    External jacket: flame retardant super flex pvc Black

    Part N.CableDiameter
    7Z4SX254 G 2.5 mm2Ø 10,5 mm
  • Speaker Power Line Cable

    Speaker Power Line Cable

    Speaker Power Line Cable

    for SSX 16pin with 4 - way grommet

    for SSX 16pin with 4 - way grommet

    This range of Syntax® cables has been developed to obtain maximum flexibility and excellent mechanical properties. The main characteristic is the extremely dense stranding of the conductors’ section, which results in increased conductivity. They feature large conductor size to minimize resistance to high power conduction. All the conductors are numbered and maintained properly clustered inside the outer PVC sheath thanks to the internal lined ridges, even under heavy usage and continuous rewinding. The cores are talc dusted to slide against one another, thus granting optimal handling. The external diameter is perfectly suitable for usage with the most commonly used power connectors. Finally, the arctic polymer PVC jacket allows good flexibility and handling in a wide range of temperatures.

  • Technical data

    Technical data

    Conductors OFC strand: section 4.0 mm² = 224 x 0.15 - 11 AWG
    Operating temperature:     - 30° + 70° c.
    D.C.R. 20° C.:     sect. 4.0 mm = 5 Ω/km
    Operating voltage:     <50 VC
    External jacket:     flame retardant super flex pvc Black

    Part N.CableDiameter
    7Z4SX404 G 4 mm2Ø 13,5 mm

  • Cables for SSX 16pin with 8 - way grommet

    Cables for SSX 16pin
    with 8 - way grommet
  • Speaker Power Line Cable

    Speaker Power Line Cable

    Speaker Power Line Cable

    for SSX 16pin 8 - way grommet

    for SSX 16pin 8 - way grommet

    This range of Syntax® cables has been developed to obtain maximum flexibility and excellent mechanical properties. The main characteristic is the extremely dense stranding of the conductors’ section, which results in increased conductivity. They feature large conductor size to minimize resistance to high power conduction. All the conductors are numbered and maintained properly clustered inside the outer PVC sheath thanks to the internal lined ridges, even under heavy usage and continuous rewinding. The cores are talc dusted to slide against one another, thus granting optimal handling. The external diameter is perfectly suitable for usage with the most commonly used power connectors. Finally, the arctic polymer PVC jacket allows good flexibility and handling in a wide range of temperatures.

  • Technical data

    Technical data

    Conductors OFC strand: section 2.5 mm² = 147 x 0.15 - 13 AWG
    Operating temperature:     - 30° + 70° c.
    D.C.R. 20° C.:     sect. 2.5 mm² = 8 Ω/km
    Operating voltage:     <50 VC
    External jacket:     flame retardant super flex pvc Black

    Part N.CableDiameter
    7Z2SX252 G 2.5 mm2Ø 8,8 mm
