SSX 19 pin
Reverse series
A whole new perspective!
SSX 19 pin
Reverse series
A whole new perspective!
Give some latitude to your fantasy on power, audio and lighting. UL Compliant.
-
When you want
unique connectionsWhen you want
unique connectionsInvert male with female and locking ring with ramps
Invert male with female
and locking ring with rampsLike all the connectors in the Syntax® SSX series, the Reverse version is designed for professional applications, is extremely robust, being made of thick wall construction machined aluminium alloy, with a hard black anodized finish or black painted finish. The contacts insert is chloroprene rubber, which enables the use of removable contacts, either crimp or solder version. The unit is completely IP67 watertight when mated. Electrical safety and compliance is guaranteed by internal insulation of the shells, obtained through a safety insulating sleeve to prevent electric shock, as well as “first make last break” ground contacts. Grounding rings allow bussing of the ground contacts. Locking rings and backshells are designed for easy handling.
-
Inline male
Inline male
with M40 cable gland
with M40 cable gland
-
Inline male
Inline male
with M40 cable gland
with M40 cable gland
-
Size 11 contacts
Rated current 23amp, max current 41amp.
The heart of the system.Size 11 contacts
Rated current 23amp, max current 41amp.
The heart of the system.We cannot trust anyone else,
we design and machine our contacts
entirely in houseWe cannot trust anyone else,
we design and machine our contacts
entirely in house -
Anti-rotation shell and insert design
Anti-rotation shell and insert design
The true value of things
is in the detailsThe true value of things
is in the details -
The anti-rotation inserts are available in different colors.
For custom color options, please contact our sales department. -
-
Multiway SSX rubber grommets
Multiway SSX rubber grommets
Manage your connections
the smart wayManage your connections
the smart way
Syntax® SSX Multiway connectors are alternative versions of the SSX standard inline connectors, designed for quick and easy managing of breakout applications. The Syntax proprietary 4, 6 or 8 way rubber grommets, fitted in the cable gland, guarantee optimal cable retention and IP67 watertight seal for outdoor use.
-
1. Safety insulating sleeve | 2.Wide backshell for easier wiring | 3. Customized cable gland | 4. 8-way rubber grommet | 5. Syntax® Mainflex cable
1. Safety insulating sleeve | 2.Wide backshell for easier wiring | 3. Customized cable gland | 4. 8-way rubber grommet | 5. Syntax® Mainflex cable
The special 8-way rubber insert, lodged in the cable gland terminal, offers the opportunity to get optimal cable retention and perfect IP67 waterproof sealing necessary for outdoor applications.
-
Metric cable glands
Metric cable glands
for the SSX Reverse connectors
for the SSX Reverse connectors
Metric thread cable glands allow more versatility compared to PG or other thread types. The reverse SSX connector is typically used with a M40 cable gland, as well as the 4-way grommet solution, while the 6-way and the 8-way grommets are used in combitation with a M50 gland.
-
Metric cable glands
Metric cable glands
Dimensions
Dimensions
V (thread size) ØS (clamping range) K Z L M 40 Q 15 - 23 mm 46 mm 10 mm 52 mm M 40 P 19 - 28 mm 46 mm 10 mm 52 mm M 40 R 22 - 32 mm 46 mm 10 mm 52 mm M 50 24 - 38.5 mm 68 mm 13.5 mm 63 mm -
Overall dimensions
Overall dimensions
-
Inline female
Inline female
Dimensions in mm
-
Inline male
Inline male
Dimensions in mm
